motor controller
Efficient, Compact, Precise: Motor Mastery
An ideal partner for pedelecs!
Our state-of-the-art motor controller offers unparalleled configurability, accommodating varied battery packs. With direct torque and advanced field oriented control, it provides accurate handling and enhanced performance. It establishes a new benchmark for motor control technology with JIVA for rider torque estimation without torque sensors!
Know MoreUSP
High Performance
Optimal efficiency through high-performance controls.
Smooth Integration
Effortless incorporation into your products through tighter integration, compared to 50% lesser volume of other motor controllers.
Compatibility
Unanimously works with the majority of displays in the market.
Infinite Possibility
Optional real time telematics!
specifications
The BLDC motor control comes with a high performance, tiny form factor.
For external LCD communication protocol, this has a UART built in. Using watertight connectors prevents dust and water from entering the enclosure. External signals are inclusive of brakes, key switch, cadence, and lights.
dimensions
Compact without an external case:
69.05 x 55.5 x 20.5 mm
Super sleek with an external case:
73 x 57 x 28 mm
protection & control
Protection protocol: Phase over current, under-voltage, over temperature
Control mode: Field Oriented Control
phase current
Maximum phase current (for 1 min) : 17A
Nominal phase current: 13A
Operating voltage (nominal) : 36V
display support
Kungteng (LED and LCD)
Kingmeter (LED and LCD)
On demand, there are others!
